MRX condensing gas air curtain
Condensing air curtain for industrial doors with a very fast warm jet and efficiency up to 107 %.
Power
11–45kW
Models
1
Gas
G20 / G25 / G31
11–45 kW
G20 · G25 · G31
01Advantages
Advantages
- Laminar air jet
- Gas savings between 15 % and 45 %
- Record combustion efficiency of 107 %
- Continuous modulation from 30 % to 100 %
- Very fast warm-air start in under 40 seconds
- Complete safety with no flame or combustion gases in the air flow
- Corrosion-resistant components
- No pollution of reheated air thanks to separated air and combustion circuits
02Description
Description
MRX uses a pre-set mini-boiler with a condensing exchanger and modulating premix burner.
The copper tube exchanger with high thermal conductivity transfers heat rapidly into the air flow.
The fan blades are aerodynamically profiled, and discharge is shaped by a single-deflection grille and laminar diffuser.
Flue pipes are high-density polypropylene because flue-gas temperature is low.
03Technical characteristics
Technical characteristics
Technical characteristics
| MRX50 | ||
|---|---|---|
| Heating value LHV | kW | 11 - 45 |
| Rated power | kW | 11.9 - 43.7 |
| Efficiency at full load | % | 98 |
| Efficiency at minimum load | % | 107 |
| Air flow at 15 °C | m³/h | 6 000 |
| Electrical power | W | 640 |
Dimensional drawing
04Applications
Applications
Logistics centresIndustrial doors 3–6 mUnloading baysService entrances
